The Daniel Defense M4, V5 uses a Cold Hammer Forged 16” Government profile barrel with a mid-length gas system. It carries the DDM4 Rail™ 12.0, perfectly adapted for end-users who need valuable rail real estate for accessories that fit their shooting needs. QD Swivel attachment points are integrated into the front and rear on both sides of the rail for fully ambidextrous sling attachment. The DDM4v5 is equipped with a single pinned low profile gas block that is drilled, taper reamed, and press fit into place to securely attach to the barrel assembly. This rifle also comes with the newly designed, rugged and comfortable Daniel Defense Buttstock and Pistol Grip and is finished with Daniel Defense Tornado™ Cerakote.
The California Compliant Model includes Bullet Button and 10 Round Magazine.
Features :
- Caliber: 5.56 NATO
- Lower Receiver: Mil-Spec with Enhanced Flared Magazine Well and Rear Receiver QD Swivel Attachment Point. CNC Machined of 7075-T6 Aluminum
- Upper Receiver: Mil-Spec with Indexing Marks and M4 Feed Ramps. CNC Machined of 7075-T6 Aluminum
- Barrel: Chrome Moly Vanadium Steel, Cold Hammer Forged, 1:7 twist, 16? Government Profile, Chrome Lined, MP tested, and Mil-Spec Heavy Phosphate Coated
- Magazine: 10 Round
- Gas System: Pinned Low Profile Gas Block CNC Machined of 4140 hardened steel and Mil-Spec Heavy Phosphate Coating, Mid-length, Direct Impingement
- Muzzle Device: Daniel Defense Flash Suppressor, 17-4 PH Stainless Steel, Salt Bath Nitride Finished
- Bolt Carrier Group: M16 Profile, Mil-Spec MP Tested, Chrome Lined, Properly Staked Gas Key
- Buffer: H Buffer
- Sights: Sold Separately
- Handguard: Daniel Defense DDM4 Rail™ 12.0, CNC Machined of 6061-T6 Aluminum
- Receiver Extension: 6 Position Mil-Spec 7075-T6 Aluminum
- Buttstock: Daniel Defense Buttstock, Glass Filled Polymer with Soft Touch Overmolding
- Pistol Grip: Daniel Defense Pistol Grip, Glass Filled Polymer with Soft Touch Overmolding
- Rail Ladders: 3 low profile ladders made from Santoprene, heat resistant to 300° F.
- Finish: Daniel Defense Tornado™ Cerakote™
- Made in the USA
The information below comes from our Gun Caliber Dictionary and is for
general reference only. It does not describe the specifications of this
particular item.
The 5.56X45mm NATO cartridge was designed by James Sullivan, a member of Eugene Stoner's engineering team that developed both the M16 rifle and its original cartridge. The 5.56X45mm NATO was adopted by the U.S. military in 1964 and by NATO in 1980. With bullet diameter of .224-inch, the original M193 military cartridge used a 55-grain bullet at 3250 fps; the current M855A1 cartridge, developed by FN, uses a 62.5-grain bullet at 3020 fps, offering greater range and better penetration. The civilian version of the 5.56X45mm is 223 Remington; the cartridges are dimensionally identical but military chamber dimensions and specifications for military brass are different. It is considered safe to use 223 Remington ammo in a 5.56X45MM NATO chamber, but not a good idea to use 5.56X45mm ammo in a rifle specifically chambered for the 223 Remington. Although the stopping power of .22-caliber bullets remains controversial the 5.56X45mm has served well in now multiple generations of M16 rifles.
—
Craig Boddington
