Pulsar Quantum Lite XQ30V 2.5-10 x 23mm Thermal Monocular Md: 77338
Pulsar

Pulsar Quantum Lite XQ30V 2.5-10 x 23mm Thermal Monocular Md: 77338

Item #11190049 MPN PL77338 UPC NOUPC302091
Pulsar Quantum Lite XQ30V 2.5-10 x 23mm Thermal Monocular Md: 77338



Features:

- Color palettes

- Rangefinding reticle

- High image frequency

- Operating modes

- Display OFF

- Power saving mode

- Calibration

- Body

- Wide range of operating temperatures

- Brightness and contrast control

- Self-contained power supply

- Video output

- External power supply

- User interface

- Controls



Specifications:

Electronic Components

- Frame Rate: 50Hz

- Microbolometer resolution: 384x288 pixels

- Pixel Pitch: 17µm

- Display type: AMOLED

- Display Resolution: 640x480 pixels



Optical Characteristics

- Magnification: 2.5 ... 10

- Digital zoom: 2x; 4x

- Objective Lens: F30/1.6

- Field of View,Degrees, horizontal * vertical : 12.4x9.3

- Horizontal Field of view, m @100m : 21.8

- Exit pupil: 8mm

- Eye Relief: 20mm

- Diopter adjustment, dptr.: ± 5



Optical Characteristics

- Close-up distance: 3m



Range of Detection

Range of detection (object high*width = 1,7*0,5m): 900m



Power Supply

- Power Supply, V: 4 ÷ 6

- Battery type: 4 x AA

- Battery Life, hour: 5.5 ... 6.5 (video out off)

- External Power Supply: DC 8.4 ÷ 15



Physical and Operational Characteristics

- Start-up time, seconds: 5

- Remote control: wireless

- Operating Temperature, Degrees: 25 … +50

- Level of Protection (acc. to IEC 60529): IPX4

- Dimensions : 200mm x 86mm x 59mm

- Weight (without batteries): 0.35 kg
